Technical Specifications for YSS Kawasaki Ninja 300 Rear Mono Shock Absorber (2013-2016) - Topline Series

• Year: 2013-2016
• Product Group: Topline
• Shock Type: Rear Mono Shock
• Product Type: Emulsion Gas Shock
• ABE: Not specified
• Length: 275-285 (mm)
• Top Dimensions: 12x35 (mm)
• Bottom Dimensions: 12x60 (mm)
• Spring Dimensions: 46-150-140 (mm)
• Piston Size: 36 (mm)
• Shaft Size: 16 (mm)

Adjustability Features:

1. Thread Spring Preload:

   • Description: Fine-tune the spring preload using a threaded spring or adjustable spring screw.
   • Adjustment Type: Thread Spring Preload
   • Fixation: Secured with a provided bolt

2. Rebound Adjustable:

   • Description: Control the shock absorber's recovery speed, adjustable for fast or slow responses.
   • Adjustment Type: Rebound Adjustable
   • Features: Volume control knob, needle shaft, Free Bleed oil through hole
   • Dial: Time adjustment dial for precise tuning

3. Length Adjustable:

   • Description: Increase the shock absorber length for personalized configuration.
   • Types: Upgradeable to 10 mm or adjustable lengths /- 5 mm.
